460V 1/2HP Single Phase Asynchronous Fan Motor For Air Conditioner

Air conditioner fan motor is a kind of HVAC AC motor. Each OEM replacement A/C motor extends equipment life by replacing old or damaged HVAC motors in ventilator, fan, and blower. Our air conditioning motors match the equipment's existing motor well by ensuring consistent performance and correct installation.
  • YSK140-375-6A11

  • Tingertech

  • 275W

  • 50Hz, 60Hz, 50/60Hz

Availability:
Quantity:

Product Description

Air conditioner fan motor is a kind of HVAC AC motor. Each OEM replacement A/C motor extends equipment life by replacing old or damaged HVAC motors in ventilator, fan, and blower. Our air conditioning motors match the equipment's existing motor well by ensuring consistent performance and correct installation.


Nomenclature for Motor:


YS(D)K140-150-6A

Y: asynchronous motor

S: Dual shaft

D: Single shaft

K: Air conditioning

140: Motor frame (outer diameter of stator)

150: Motor output power

6: Number of poles

A: Factory design code (or customer code, etc.)


Motor featurers:


1. Portable air conditioner, movable air conditioner, mobile air conditioner

2. Window air conditioner

3. Commercial air conditioner

4. Air curtain

5. Fresh air ventilation



Benefits:


  • Low noise

  • High efficiency

  • Reliable

  • Low vibration


Technical specification:

Item

Air Conditioner Fan Motor

Motor Application

HVAC/R

Motor Sub Application

Condenser Fan

Phase

Single

Motor Design

Permanent Split Capacitor

Hz

50/60

No. of Speeds

1

Voltage

220-240V

Output

275W

Nameplate RPM

880

Frame

140mm

Motor Service Factor

1

Motor Thermal Protection

Auto

Ins. Class

B

Duty Cycle

Continuous

Max. Ambient Temp.

60 Degrees C

Motor Shaft Rotation

CW/CCW

Motor Enclosure Design

Close Dripproof

More models:


Listed are representative motors, only for reference, dimensions and parameters can be customized according to customer requirements, OEM/ODM offered.

Model Number

Voltage

/V

Frequency

/Hz

Power

Speed

/RPM

Capacitor

/MDF/VAC

OEM Model

YSK140-375-6A

208-230

60

1/2HP

1075

10/370

5KCP39MGK209T

YSK140-375-6A3

208-230

60

1/2HP

1075/3 SPD

7.5/370

FASCO D703

YSK140-375-6A7

208-230

60

1/2HP

1075

10/370

5KCP39PGG404ET

YSK140-375-4A9

208-230

60

1/2HP

1625/3 SPD

5/370

PM3102186

YSK140-375-6A10

115

60

1/2HP

1075

5/370

PM3102185


YDK140-120-6A5 (3)

FAQ

FAQ:


1. Q: How we get a same motor as we need?

A: For your same motor, please share us:

a.Your motor image and nameplate;

b.Detailed size of your motor.


2. Q: Can you provide us sample, is it free or need to pay?

A: Free sample is always available, freight cost on customer's side.


3. Q: What's your payment term?

A: 30% deposit and 70% balance before shipping by LC,TT on FOB term.


4. Q: What kind of product you can provide?
A: As a professional factory of hvac motor and centrifugal fan (housing fan), many different motor models and centrifugal duct fans are on our list: fan coil unit motor for central air conditioner, motor for split, cabinet, window, ceiling air conditioner, cooler motor, blower motor, fan motor, heat pump motor, universal fan motor, indoor fan motor, outdoor fan motor, condenser fan motor, PG motor, and other HVAC/R MOTOR; BLDC motor, EC motor, stepper motor, single and three phase motor; AC Centrifugal fan, EC centrifugal blower as well as other HVAC parts, which are on our service to help cusotmer purchase.


5. Q: Is there a MOQ for your motors?
A: Yes. The MOQ is between 100-500pcs for different models after sample approval. And it's also okay for us to accept smaller lots for the initial order.


6. Q: Could you send me a price list?
A: Most of our motor are not standard products, they are customized based on different requirements like voltage, power and shaft dia and length etc. Thus, it's really difficult for us to provide a price list. If you could share your detailed requirements and quantity, we'll be sure to offer a very competitive price.
