Suitable for Beautiful Brushless DC Motor DB31-00643A Fan Motor SIC-81FW-F1139-1

DC MOTOR is a motor converts supplied electrical energy into mechanical energy. Various types of motors are in common use. Brushless DC motor (BLDC) ,also known as an electronically commutated motor (ECM or EC motor) features high efficiency and excellent controllability. The BLDC motor has power-saving advantages relative to other motor types. Our brushless motor main uses in air conditioner or fan coil unit or centrifugal fan.
  • DB31-00643A

  • Tingertech

  • 50Hz  60Hz  50/60Hz

Availability:
Quantity:

Product Description

DC MOTOR is a motor converts supplied electrical energy into mechanical energy. Various types of motors are in common use. Brushless DC motor (BLDC) ,also known as an electronically commutated motor (ECM or EC motor) features high efficiency and excellent controllability. The BLDC motor has power-saving advantages relative to other motor types. Our brushless motor main uses in air conditioner or fan coil unit or centrifugal fan.


Nomenclature for Motor:


YS(D)K140-150-6A

Y: asynchronous motor

S: Dual shaft

D: Single shaft

K: Air conditioning

140: Motor frame (outer diameter of stator)

150: Motor output power

6: Number of poles

A: Factory design code (or customer code, etc.)


Motor featurers:


1. Our motor use nickel plating for shaft,electrophoretic coating for enclosure.

2. The bearing use nsk low noise high quality ball bearing.


Technical Specification:


Item

Cooler motor

Motor Application

HVAC/R

Motor Sub Application

Air cooler motor

Phase

Single

Motor Design

Permanent Split Capacitor

Hz

50/60

Nameplate RPM

850

No. of Speeds

1

Voltage

220-240V

Full Load Amps

0.50A

Frame

95mm

Motor Service Factor

1

Motor Thermal Protection

Auto

Ins. Class

B

Duty Cycle

Continuous

Max. Ambient Temp.

60 Degrees C

Motor Shaft Rotation

CW/CCW

Motor Enclosure Design

Close Dripproof


FAQ

FAQ:


1. Q: How we get a same motor as we need?

A: For your same motor, please share us:

a.Your motor image and nameplate;

b.Detailed size of your motor.


2. Q: Can you provide us sample, is it free or need to pay?

A: Free sample is always available, freight cost on customer's side.


3. Q: What's your payment term?

A: 30% deposit and 70% balance before shipping by LC,TT on FOB term.


4. Q: What kind of product you can provide?
A: As a professional factory of hvac motor and centrifugal fan (housing fan), many different motor models and centrifugal duct fans are on our list: fan coil unit motor for central air conditioner, motor for split, cabinet, window, ceiling air conditioner, cooler motor, blower motor, fan motor, heat pump motor, universal fan motor, indoor fan motor, outdoor fan motor, condenser fan motor, PG motor, and other HVAC/R MOTOR; BLDC motor, EC motor, stepper motor, single and three phase motor; AC Centrifugal fan, EC centrifugal blower as well as other HVAC parts, which are on our service to help cusotmer purchase.


5. Q: Is there a MOQ for your motors?
A: Yes. The MOQ is between 100-500pcs for different models after sample approval. And it's also okay for us to accept smaller lots for the initial order.


6. Q: Could you send me a price list?
A: Most of our motor are not standard products, they are customized based on different requirements like voltage, power and shaft dia and length etc. Thus, it's really difficult for us to provide a price list. If you could share your detailed requirements and quantity, we'll be sure to offer a very competitive price.
