TG-12 Shock-Resistant Pressure Gauge

Tingertech mainly produces and deals in common pressure gauges, oxygen/acetylene pressure gauges, medical pressure gauges, liquid-filling pressure gauges, chemical industrial pressure gauges refrigerant pressure gauges, capsule pressure gauges and partial refrigeration parts.

  • TG-12
  • Tingertech
Availability:
Quantity:

Product Description

Tingertech mainly produces and deals in common pressure gauges, oxygen/acetylene pressure gauges, medical pressure gauges, liquid-filling pressure gauges, chemical industrial pressure gauges refrigerant pressure gauges, capsule pressure gauges and partial refrigeration parts.


Application


  1. For measuring points with high dynamic pressure loads and vibrations;

  2. Suitable for refrigerant media measure the relation of pressure;

  3. Heat pump system;

  4. Refrigeration test manifolds;

  5. Air conditioning system



Product feature


1. Conforms to the standard of the People's Republic Of China General Pressure Gauge, GB/T1226-2017 and the standard of EN837-1;

2. Size (mm)40, 50, 60, 70, 80, 90, 100;

3. Permissible temperature: Ambient: Media:+60℃ (maximum);

4. Accuracy class: ±1.6% F.S;

6. Range: 0~16MPa;

7. Protection grade: IP54


Specifications


1. Meterial: 304 Stainless steel;

2. Connection: 1/8" NPT 7/16-20UNF 5/16-24UNF;

3. Installation form: Lower mount (LM), Center back mount (CBM),

Back panel mount (BPM), Lower surface mount (LSM);

4. Type for Refrigerant media: R22 P134a R404A R410A R407c R704 R433B R407F R502 R507A R607c R600a R406


Product No.
A B C D E G E G M N S T W
BE3.338 68 56 30 62 11 / 85 / 85 75.5 6
/ 14
BD4.338 55 / 27 50 / 52 70 52 70 62 6 / 14
BE4.338 68 / 30 62 / 61 85 61 85 75.5 6 / 14
BE5.338 68 / 30 62 / 56 / 56 / 72 6 M5 14


Outline drawing

TG-04(3)


YDK50-6 (1)

Gauge Selection Table

GaugeYDK50-6 (6)YDK50-6 (8)
