YDK120-60-6 60W Heat Pump Outdoor Fan Motor For Central Air Conditioner

Heat Pump Fan Motor is designed for condenser fan and heat pump units requiring vertical shaft up or vertical shaft down positioning.Find Heat Pump Motor Replacement at Tingertech, who is fan motor manufacturer,supplier,exporter, wholesaler,sellers,hvacr for heat pump.
  • YDK120-60-6

  • Tingertech

  • 60W

  • 50Hz, 60Hz, 50/60Hz

Availability:
Quantity:

Product Description

Heat Pump Fan Motor is designed for condenser fan and heat pump units requiring vertical shaft up or vertical shaft down positioning.Find Heat Pump Motor Replacement at Tingertech, who is fan motor manufacturer,supplier,exporter, wholesaler,sellers,hvacr for heat pump.




Nomenclature for Motor:


YS(D)K140-150-6A

Y: asynchronous motor

S: Dual shaft

D: Single shaft

K: Air conditioning

140: Motor frame (outer diameter of stator)

150: Motor output power

6: Number of poles

A: Factory design code (or customer code, etc.)


Motor featurers:


1. Safe and reliable, low noise, good starting, long life, etc.

2. Insulation class E/B/F, protection class IP20~IP54.

3. Rolling bearing, NSK low noise high quality material.

cooler motor, air conditioner motor, ac motor, fan motor, blower motor.

4. Special motors can be designed according to customer's requirement. Pure copper coil or copper clad aluminum coil can be chosen.


Technical specification:

Item

Heat pump fan motor

Motor Application

HVAC/R

Motor Sub Application

Condenser Fan

Phase

Single

Motor Design

Permanent Split Capacitor

Hz

50/60

No. of Speeds

1

Voltage

220-240V

Output

60W

Nameplate RPM

880

Frame

120mm

Motor Service Factor

1

Motor Thermal Protection

Auto

Ins. Class

B

Duty Cycle

Continuous

Max. Ambient Temp.

60 Degrees C

Motor Shaft Rotation

CW/CCW

Motor Enclosure Design

Close Dripproof

More models:


Listed are representative motors, only for reference, dimensions and parameters can be customized according to customer requirements, OEM/ODM offered.

Model Number

Voltage

/V

Frequency

/Hz

Output

/W

Speed

/RPM

Capacitor

/MDF/VAC

YDK120-45-6

208-240

50/60

45

800

3

YDK120-60-6

208-240

50/60

60

800

4

YDK139-90-6

208-240

50/60

90

800

8

YDK139-250-6

208-240

50/60

250

800

10

YDK139-250-6C

208-240

50/60

250

800

10

YT139-370-6

208-240

50/60

370

800

15



YDK120-60-6 (3)

FAQ

FAQ:


1. Q: How we get a same motor as we need?

A: For your same motor, please share us:

a.Your motor image and nameplate;

b.Detailed size of your motor.


2. Q: Can you provide us sample, is it free or need to pay?

A: Free sample is always available, freight cost on customer's side.


3. Q: What's your payment term?

A: 30% deposit and 70% balance before shipping by LC,TT on FOB term.


4. Q: What kind of product you can provide?
A: As a professional factory of hvac motor and centrifugal fan (housing fan), many different motor models and centrifugal duct fans are on our list: fan coil unit motor for central air conditioner, motor for split, cabinet, window, ceiling air conditioner, cooler motor, blower motor, fan motor, heat pump motor, universal fan motor, indoor fan motor, outdoor fan motor, condenser fan motor, PG motor, and other HVAC/R MOTOR; BLDC motor, EC motor, stepper motor, single and three phase motor; AC Centrifugal fan, EC centrifugal blower as well as other HVAC parts, which are on our service to help cusotmer purchase.


5. Q: Is there a MOQ for your motors?
A: Yes. The MOQ is between 100-500pcs for different models after sample approval. And it's also okay for us to accept smaller lots for the initial order.


6. Q: Could you send me a price list?
A: Most of our motor are not standard products, they are customized based on different requirements like voltage, power and shaft dia and length etc. Thus, it's really difficult for us to provide a price list. If you could share your detailed requirements and quantity, we'll be sure to offer a very competitive price.
