Level Wound Copper Coil Pancake Copper/brass Capillary Tube Coil for Air Conditioner

Tingertech capillary tube is divided into coiled tube and straight tube. The coiled tube has a Coil weight ranging from 15-70KG, which can be customized according to customer needs. The length of the straight pipe ranges from 20mm to 3m. At the same time, the straight pipe can be shaped in ends, including expansion, shrink, bulge etc.

  • Level Wound Copper Coil
  • Tingertech
Availability:
Quantity:

Product Description

Tingertech capillary tube is divided into coiled tube and straight tube. The coiled tube has a Coil weight ranging from 15-70KG, which can be customized according to customer needs. The length of the straight pipe ranges from 20mm to 3m. At the same time, the straight pipe can be shaped in ends, including expansion, shrink, bulge etc.


Feature

Clean surface, bright finish, even structure,high-precision size,welding easily,good shaping.


Applications

Used in heat exchanger and piping system connection in air conditioning and refrigeration industry.


Advantages

1. Standard: JISH3300:1997,GB/T17791-2007,ASTM B280

2. Top quality copper material C1220/SF-Cu/C12000

3. Made by EXTRUSION process, perfect size tolerance.

4. All pipes are checked by on line Eddy Current Inspection to ensure all the pipes are qualified products.

5. Smooth and clean Outer/inner surface, no smudge and rust.

6. Easy to braze and anti-corrosion

7. Long service life and recyclable.

8. Can be used for liquid fed applications such as air conditioning, ice makers, humidifiers, and refrigeration systems. Also used for oil lines for heating.


Tenchnical Date

O.D.(inch)O.D.(mm)Wall Thickness(mm)Length
Thickness Range AvailiableRegular Thickness
3/8"9.520.28-1.50
3m/pc
1/2"12.70.35-2.00
5/8"15.880.46-2.001
3/4"19.050.6-2.001
7/8"22.220.6-2.001
1"25.40.6-2.001
11/8"28.580.6-3.001
11/4"31.750.6-3.001.2
13/8"34.930.6-3.001.3
11/2"38.10.6-3.001.4
15/8"41.280.7-3.501.4
16/8"44.450.7-3.501.5
21/8"53.980.7-3.501.7
25/8"66.681.0-4.002.1
31/8"79.381.2-5.00
35/8"92.081.5-5.00
41/8"107.781.5-5.00
51/8"130.18

61/8"155.58

81/8"
206.38
