Single Phase 3 Speed AC Unversial Condensing Unit Fan Motor YDK140/120 Series

Air conditioner fan motor is a kind of HVAC AC motor. Each OEM replacement A/C motor extends equipment life by replacing old or damaged HVAC motors in ventilator, fan, and blower. Our air conditioning motors match the equipment's existing motor well by ensuring consistent performance and correct installation.
  • AC Unversial Condensing Unit Fan Motor YDK140/120 Series

  • Tingertech

  • 1/6HP

  • 50Hz  60Hz  50/60Hz

Availability:
Quantity:

Product Description

Nomenclature for Motor:


YS(D)K140-150-6A

Y: asynchronous motor

S: Dual shaft

D: Single shaft

K: Air conditioning

140: Motor frame (outer diameter of stator)

150: Motor output power

6: Number of poles

A: Factory design code (or customer code, etc.)


Motor featurers:


1. The motor have low Noise,reasona structure,high efficiency.

2. Steady quatlity.

3. Insulation class E/B/F,protection class IP00-IP54.

4. Large Wind Amount.

5. Providing Imported equipment & technical assistance.

6. Low temperature rise and a strong adaptability to the environment.

7. 100% pure copper, aluminum motor can also be available if customer need large quantity.


Technical specification:

Powerstar:

Powerstar

Type:

Asynchronous Moter

Rated Voltage

208-230

Frequency:

50/60hz

Output Power:

1/6-1/2

RPM:

825/1075

Protect Feature:

totally enclosed

Speed:

3

APMS:

1-3.9

Rotation

REV

Phase:

Single-phase

Bearing:

Ball bearing

Place of Origin:

Guangdong China (Mainland)

Certification:

ROHS,UL

Features:

A. smooth running,
B. long work times and Low temperature
C. low noise,
D. steady performance.

Specifications:

• Reversible plug for easy rotation
• Class H Insulation
• Quick installation
• Energy efficient
• Quiet operation
• Ball bearing
• Dual voltage 115/208-230 voltage
• Diameter: Steel cover144mm
• Automatic overload
• Operating temp -10-43 degree
• Power:150-250W

• Rated Frequency:50/60Hz

• Number of Pole: 6/8Pole
• Shaft size:15mm
• Speed: 825-1075rpm
• Thermal protection
• High efficiency,High reliability,Little vibration,Low noise

OEM/ODM: Yes and Welcome

Material: Metal,Aluminum cover

Process: Paint or plate/inspection/Printing

Output power: 1/3hp,1/4hp

Voltage,frequency: 208-230V 50/60Hz

Speed: 1300-1500rpm

Logo: trusTec or customer logo

Packing: carton box

Usage: refrigerator,condensing unit,air cooler

Sample time: 7 days

Lead time: 30 days

Shipping: By sea/By air from shanghai port.(you can choose any port you want shipping)

              By express: TNT/DHL/FEDEX/UPS/EMS etc.

Technical Parameters


Model No.

Parameter

Century Genteq Fasco Marathon
YDK140-185-6C 1/4HP 115V 60Hz 1075/3 RPM FDL1026 3583 D721 X000
YDK140-250-6C 1/3HP 115V 60Hz 1075/3 RPM FDL1036 3585 D727 X002
YDK140-375-6C 1/2HP 115V 60Hz 1075/3 RPM FDL1056 3587 D701 X004
YDK140-550-6C 3/4HP 115V 60Hz 1075/3 RPM DL1076 3589 D728 X009
YDK140-185-6D 1/4HP 208-230V 60Hz 1075/3 RPM D1026 3584 D725 X001
YDK140-250-6D 1/3HP 208-230V 60Hz 1075/3 RPM FD1036 3586 D923 X003
YDK140-375-6D 1/2HP 208-230V 60Hz 1075/3 RPM FD1056 3588 D703

X005

YDK140-550-6D 3/4HP 208-230V 60Hz 1075/3 RPM D1076 3590 D729 X010
YDK140-375-6C2 1/2 1/3 1/4 1/5 1/6 HP 115V 60Hz 1075/4 RPM FDL6001 3463 D2835 X073
YDK140-550-6C2 1/2 1/3 1/4 1/5 3/4 HP 115V 60Hz 1075/4 RPM FDL6002 3466 D2832 X075
YDK140-375-6D2 1/2 1/3 1/4 1/5 1/6 HP 208-230V 60Hz 1075/4 RPM FDL6000 3464 D833

X077

YDK140-550-6D2 1/2 1/3 1/4 1/5 3/4 HP 208-230V 60Hz 1075/4 RPM FD6001 3467 D2833 X074


Note: Listed are representative motors, only for reference, dimensions can be customized according to customer requirements, OEM & ODM offered.


Single Phase 3 Speed AC Unversial Condensing Unit Fan Motor YDK140 120 Series


Our service:


  • Honesty,Good Efficiency and Provide the Best Service

  • We are able to develop new motor and produce it according to your requirement, please provide with your drawing & sample.

  • Our advantage: good quality, low price, prompt delivery, strong R&D ability.


FAQ

FAQ:


1. Q: How we get a same motor as we need?

A: For your same motor, please share us:

a.Your motor image and nameplate;

b.Detailed size of your motor.


2. Q: Can you provide us sample, is it free or need to pay?

A: Free sample is always available, freight cost on customer's side.


3. Q: What's your payment term?

A: 30% deposit and 70% balance before shipping by LC,TT on FOB term.


4. Q: What kind of product you can provide?
A: As a professional factory of hvac motor and centrifugal fan (housing fan), many different motor models and centrifugal duct fans are on our list: fan coil unit motor for central air conditioner, motor for split, cabinet, window, ceiling air conditioner, cooler motor, blower motor, fan motor, heat pump motor, universal fan motor, indoor fan motor, outdoor fan motor, condenser fan motor, PG motor, and other HVAC/R MOTOR; BLDC motor, EC motor, stepper motor, single and three phase motor; AC Centrifugal fan, EC centrifugal blower as well as other HVAC parts, which are on our service to help cusotmer purchase.


5. Q: Is there a MOQ for your motors?
A: Yes. The MOQ is between 100-500pcs for different models after sample approval. And it's also okay for us to accept smaller lots for the initial order.


6. Q: Could you send me a price list?
A: Most of our motor are not standard products, they are customized based on different requirements like voltage, power and shaft dia and length etc. Thus, it's really difficult for us to provide a price list. If you could share your detailed requirements and quantity, we'll be sure to offer a very competitive price.
