Tinger is a flourishing High-Tech enterprise which was founded in 2002. We specialize in developing and manufacturing the hermetical and semi-hermetic compressors & units, and all kinds of refrigeration parts such as the Filter Drier, Liquid Accumulator and OiI Separator.
Before returning to the compressor refrigeration cycle system,when the refrigerant must complete gasification.So before the refrigerant entering the compressor must separate the gas and liguid,gas liguid refrigerant entering the compressor does not happen cause the compressor;Slowly from the liquid refrigerant in the separator,after waiting for evaporation into the compressor.In order to make the remaining frozen oil back to the compressor in the system,at the bottom of the muffler in the gas-liquid separator is euqipped with oil return hole,the remaining frozen oil will be return to the compressor with gas refrigerant.With the protection of the gas-liquid separation,the life of the compressor will be more durable and operation of the system to function.
Features
1, U-bend desgin ensures maximum refrigerant flow and intercept the least oil.
2, Into the fluid with the u-bend tube guide stagger,prevent the liquid refrigerant entering the compressor directly. 3, Surface coated with corrosion resistant epoxy powder coating,
Model | Connection Size (inch) | Dimensions(mm) | Nominal capacity(Kw) at the following evaporating temperature | Volume (L) |
ΦD | H | H1 | A | R22 | R22 | R134a | R134a | R404a | R404a |
-18ºC | 5ºC | -18ºC | 5ºC | -18ºC | 5ºC |
| TG-595 | 5/8" | 127 | 216 | 35 | 70 | 5.1 | 11.8 | 2.7 | 7.1 | 4.5 | 7.2 | 2.5 |
| TG-596 | 3/4 | 127 | 216 | 35 | 70 | 6.3 | 14.1 | 3.2 | 8.1 | 5.3 | 9.2 | 2.5 |
| TG-5126 | 3/4 | 127 | 298 | 35 | 70 | 6.3 | 14.1 | 3.2 | 8.1 | 5.3 | 9.2 | 3.3 |
| TG-5127 | 7/8 | 127 | 298 | 37 | 70 | 11.6 | 25.7 | 6.3 | 14.0 | 9.5 | 16.2 | 3.3 |
| TG-5137 | 7/8 | 127 | 323 | 37 | 70 | 11.6 | 25.7 | 6.3 | 14.0 | 9.5 | 16.2 | 3.6 |
| TG-5139 | 1-1/8 | 127 | 323 | 45 | 70 | 18.9 | 41.5 | 10.9 | 25.3 | 15.5 | 26.7 | 3.6 |
| TG-5179 | 1-1/8 | 127 | 426 | 45 | 70 | 18.9 | 41.5 | 10.9 | 25.3 | 15.5 | 26.7 | 5 |
| TG-51711 | 1-3/8 | 127 | 426 | 50 | 70 | 29.9 | 66.1 | 16.2 | 37.6 | 25.3 | 42.9 | 5 |
| TG-61411 | 1-3/8 | 159 | 352 | 50 | 70 | 29.9 | 66.1 | 16.2 | 37.6 | 25.3 | 42.9 | 6.5 |
| TG-62013 | 1-5/8 | 159 | 508 | 55 | 70 | 45.0 | 101.3 | 25.7 | 59.8 | 37.6 | 64.0 | 9.5 |
| TG-204 | 1/2 | 102 | 224 | 30 | 53 | 3.2 | 7.0 | 2.17 | 4.3 | 2.8 | 4.6 | 1.6 |
| TG-205 | 5/8 | 102 | 264 | 30 | 53 | 4.9 | 10.5 | 2.8 | 6.0 | 4.2 | 7.0 | 1.9 |
| TG-206 | 3/4 | 140 | 276 | 36 | 80 | 6.3 | 14.1 | 3.2 | 8.1 | 5.3 | 9.2 | 3.8 |
| TG-207 | 7/8 | 140 | 326 | 36 | 80 | 11.6 | 25.7 | 6.3 | 14.0 | 9.5 | 16.2 | 4.4 |
| TG-208 | 1-1/8 | 165 | 413 | 40 | 82 | 18.9 | 41.5 | 10.9 | 25.3 | 15.5 | 26.7 | 8 |
TG-209
| 1-3/8 | 165 | 533 | 40 | 82 | 29.9 | 66.1 | 16.2 | 37.6 | 25.3 | 42.9 | 10.5 |
| TG-210 | 1-5/8 | 165 | 583 | 40 | 82 | 45.0 | 101.3 | 25.7 | 59.8 | 37.6 | 64.0 | 11.5 |
| TG-221 | 2-1/8 | 219 | 715 | 50 | 120 | - | - | - | - | - | - | 24 |
| TG-1817 | 2-1/8 | 219 | 490 | 50 | 120 | - | - | - | - | - | - | 18 |
